1.7 Adjusting the equipment
If the frame is not level, level it by adjusting the four feet shown in the figure:
- slacken the locknut (
a);
- screw the foot (
b) in or out until the frame is in a stable position;
- tighten up the locknut after adjusting (
a).
After assembly, unscrew the screw (c) in the feet (A) on the lower arms until the feet rest on the
ground.
