8
B
A
D
E
04094005
04094007
C F
GAMMA
A Frame: this is the equipment’s supporting structure, covered by the protective panel (D).
B Upper and lower arms: the cables with handgrips (E), for performing the exercises, run
through the arms.
C Weight stack: each handgrip (E), when worked by the user, moves the weights along two
guides by means of a cable. A pin (F) is used to select the workload, to adjust the amount of
effort required.
1 teChniCal inforMation
