7.14.2 ASSEMBLING THE ANGLE SENSOR BOARD
1. Connect the cable (previously disconnected) to the angle sensor board.
2. Insert the angle sensor board in the pin, without forcing it: push the board until it's resting on
the turrets, where there are two screws. Insert the board, using two ngers to press around
the hole through which the pin is inserted (refer to the two photos below).
Figure 63 - the area where the board should be pressed in order to insert it in the pin
