© Technosoft 2011 93
IDMx40 Technical Reference
used to download and execute TML programs. It is the user’s choice to decide how to split the
32 K SRAM into data and program memory.
The E
2
ROM is seen as 4 K×16 program memory mapped in the address range: 4000h to 5FFFh.
It is used to keep in a non-volatile memory the TML programs, the cam tables and the drive setup
information.
Remark: EasyMotion Studio handles automatically the memory allocation for each motion
application. The memory map can be accessed and modified from the main folder of each
application
