Technosoft IDM240-5EI - Electrical Specifications

© Technosoft 2011 10 IDMx40 Technical Reference
2.5. Electrical Specifications
All parameters measured under the following conditions (unless otherwise noted):
 T
amb
= 0…40°C, V
LOG
= 24 V
DC
, V
24 VPLC
= 24 V
DC
, CAN_V+ = 24 V
DC
;
 V
MOT
= 48 V
DC
(IDM240-5EI) or 80 V
DC
(IDM640-8EI);
 Supplies start-up / shutdown sequence: -any-
;
 Load current 5 A
RMS
(IDM240-5EI) or 8 A
RMS
(IDM640-8EI)
Operating Conditions
Min. Typ. Max. Units
Ambient temperature
1
0 +40 ºC
Case temperature
2
Mounted on metallic surface 0 +60 ºC
Ambient humidity Non-condensing 0 90 %Rh
Altitude (referenced to sea level) 0 ÷ 1 +4 Km
Altitude / pressure
3
Ambient Pressure 0.64 0.9 ÷ 1 4.0 atm
ESD capability -see electrical characteristics-
Storage Conditions
Min. Typ. Max. Units
Ambient temperature -40 +85 ºC
Ambient humidity Non-condensing 0 100 %Rh
Altitude (referenced to sea level) 0 ÷ 1 +4 Km
Altitude / pressure
Ambient Pressure 0.64
0.9 ÷
1
4.0 atm
ESD capability Stand-alone
±8
kV
Original packaging
±15
kV
1
Applicable to stand-alone operation; Operating temperature can be extended up to +80ºC with reduced current and
power ratings. See Figure 2.14 – De-rating with ambient temperature
2
Applicable when mounted on metallic surface; Operating temperature can be extended up to +80ºC with reduced current
and power ratings. See 2.15 – De-rating with case temperature
3
At altitudes over 1,000m, current and power rating are reduced due to thermal dissipation efficiency at higher altitudes.
See 2.16 – De-rating with altitude
