IDMx40 Technical Reference
Mechanical Mounting
Min. Typ. Max. Units
Mounting direction
no restriction
Flatness ±0.1 mm
Mounting surface
Material Thermally conductive (ex: metal)
Screw head / washer diameter 5.5 M3, M4 8 mm
Fixing screws
Tightening torque 1 3 Nm
Environmental & Mechanical Characteristics
Min. Typ. Max. Units
136 x 95 x 26 mm
Size
Length x Width x Height
Without counterpart connectors
5.35 x 3.74 x 1.02 inch
Weight 0.28 Kg
Cleaning agents Dry cleaning is recommended
Only Water- or
Alcohol- based
Protection degree According to IEC60529, UL508 IP20 -
Logic Supply Input
Measured between +V
LOG
and GND.
Min. Typ. Max. Units
Nominal values, including ripple 12 24 48 V
DC
Absolute maximum values, continuous 8 +51 V
DC
Supply voltage
Absolute maximum values, surge
(duration ≤ 10ms)
†
-100 +60 V
+V
LOG
= 12V 350 400 mA
+V
LOG
= 24 V 150 250 mA
Supply current
+V
LOG
= 48 V 80 150 mA
ESD Protection Human Body Model
±25 ±30
kV
