© Technosoft 2011 12 IDMx40 Technical Reference
Motor Supply Input
Measured between +V
MOT
and GND.
Min. Typ. Max. Units
Nominal values, including ripple & braking-
induced over-voltage up to ±25%
12 48 V
DC
Absolute maximum values, continuous 0 63 V
DC
Supply voltage IDM240-5EI
Absolute maximum values, surge
(duration ≤ 10ms)
†
-0.5 65 V
Nominal values, including ripple & braking-
induced over-voltage up to ±25%
12 80 V
DC
Absolute maximum values, continuous 0 100 V
DC
Supply voltage IDM640-8EI
Absolute maximum values, surge
(duration ≤ 10ms)
†
-0.5 105 V
Idle 1.5 4 mA
Operating 16.5 A
Absolute maximum values, surge
(duration ≤ 10ms)
†
30 A
Supply current
In-rush current surge; V
LOG
=48V,
wires 1m x 1.5mm
2
≤ 300 A
PK
≤ 100 µS fall-time to 50%
Drive Efficiency P
MOTOR
/P
MOTOR_SUPPLY
; F
PWM
=20KHz 88 92 %
ESD Protection Human Body Model
±25 ±30
kV
I/O Supply Input (isolated)
Measured between +24 V
PLC
and 0V
PLC
.
Min. Typ. Max. Units
Nominal values 8 24 30 V
DC
Supply voltage
Absolute maximum values, surge
(duration ≤ 10ms)
†
-0.5
32 V
All inputs and outputs disconnected 12 25 mA
Supply current
All inputs tied to +24 V
PLC
; all outputs
sourcing simultaneously their nominal
current into external load(s)
60 180 mA
Isolation voltage rating Between 0V
PLC
and GND 200 V
RMS
