Technosoft IDM240-5EI - LED Indicators; First Power-Up

© Technosoft 2011 56 IDMx40 Technical Reference
3.4. LED Indicators
LED Color Function
Green Lit after power-on when the drive initialization ends. Turned off
when an error occurs
Red Turned on when the drive detects an error condition or when
OUT#12 is set to 24V with ROUT#12 TML instruction
3.5. First Power-Up
In order to setup the drive for your application you need to communicate with it. The easiest way
is via an RS-232 serial link between your PC and the drive. Therefore, before the first power-up,
check the following:
 Power supply connections and their voltage levels
 Motor connections
 Serial cable connections
 DIP switch positions: all shall be OFF (not pressed)
 EasySetUp is installed on the PC which is serially connected with the drive (see
chapter Step 2. Drive Setup
