© Technosoft 2011 20 IDMx40 Technical Reference
Leave the distance D
1
, D
2
and D
3
between the drive and surrounding walls/drives, to allow for free
air circulation.
Required cooling distance
D
1
> 25mm (1 in)
D
2
> 60mm (2.36 in)
D
3
> 25mm (2.36 in)
Wiring Requirement
The mounting distances D
1
, D
2
and D
3
(see Figure 3.1) should permit to connect the cables to the
drive (at least the screw driver height).
Required wiring distance
D
1
> 120mm (4.72 in)
D
2
> 100mm (3.93 in)
D
3
> 25mm (2.36 in)
