© Technosoft 2011 34 IDMx40 Technical Reference
CAUTION!
THE FEEDBACK CONNECTOR SIGNALS ARE
ELECTROSTATICALLY SENSITIVE AND SHALL BE
HANDLED ONLY IN AN ESD PROTECTED ENVIRONMENT
1
3
2
+5V DC
J13A
13
GND
+3.3V
A1+
B1+
Z1+
7
+5V
3 x 4K7
IDM240-5EI
IDM640-8EI
J13A - Feedback Connector
SHIELD
Connected
to case
- Single-ended / open-collector encoders -
+5V
DSP Controller
Figure 3.16. J13A – Single-ended / open-collector encoder connection
IDMx40
