© Technosoft 2011 37 IDMx40 Technical Reference
5
9
- Second Encoder - single (RS-422) -
J13A
13
GND
+3.3V
+1.6V
H1/B2/DT+
H2/Z2+
H3/A2/CK+
4
+5V
3 x 4K7
3 x 3K1
IDMx40
J13A - Feedback Connector
SHIELD
DSP Controller
Connected
to case
To en c o d e r
inputs
Master
Master
Figure 3.19. J13A – Second encoder – single ended (RS-422) connection
