1.7.5 Instrument Panel
The instrument panel is of conventional type, allowing space for a broad range of equipment.
Fig. 1-2 Instrument Panel
1.7.6 Carburetor Heat
Carburetor heat (if available) control knob is located just to the right of the center throttle control. When the knob is pulled
fully outward from the instrument panel, carburetors receive maximum hot air. During normal operation, the knob is OFF.
1.7.7 Cabin Heat / Defrost
The cabin heat control knob (if available) is positioned on the lower of the instrument panel; when knob is pulled fully
outward, cabin receives maximum hot air. Vents are located by the rudder pedals and above instrument panel. If necessary,
outside fresh air can be circulated inside cabin by opening the vents on the panel.
1.7.8 Throttle Friction Lock
Adjust the engine's throttle friction by tightening or loosening the friction lock located on the console side near center
throttle control.
1.7.9 Seats, Seatbelts, and Shoulder harnesses
The P2008usually comes with three point safety belts with waist and diagonal straps adjustable via a sliding metal buckle.
Standard seats are aluminum with cushions. Seats are adjustable fore and aft by using the handle located under the seat on
the outboard sides. Pushing the lever towards the center of the aircraft will release the locking pin allowing you to move the
seat fore and aft. Release the lever when the desired position is found making sure that the locking pin reengages in the seat
track.
P2008 is equipped with standard bucket seat for the access to the baggage compartment. The same lever allows the pilot to
regulate the seat in two position: 20° and 25° to increase the flight comfort.
WARNING
Make sure that the locking pin is securely installed or the seat will not lock in position.
