Tecnam P2008 - 8.1.21 Limitation Placards

66
Inside the doors, in the upper side, is located the following placard (4x50mm):
8.1.18 Identification plate
The following placard is located on the pilot side of the empennage forward of the stabilator and made of stainless steel.
8.1.19 Static port
On each static port is locate a placard diam 20mm:
8.1.20 Fuel Tank
Next each fuel tank is the following placard (40x100 mm)
8.1.21 Limitation Placards
Next to the airspeed indicator is the following placard (6x52mm).
Builder:
CostruzioniAeronauticheTecnam
Model: P2008
Serial number: XXX
Maneuvering speed V
A
= 98 KIAS
