65
8.1.13 Oil tank reservoir
On the oil tank reservoir are present two placards (30x12mm) indicating the type and quantity of engine’s oil stored into the
reservoir.
8.1.14 Cooling system overflow tank
Located on the overflow tank inside the engine cowling left side, is located the following placard (60x15mm):
8.1.15 Brake oil reservoir
On the cap of the brake’s oil tank, is a placard indicating the type of oil that must be used.
8.1.16 Tire pressures
On each steel spring leaf is a placard indicating the main tires inflating pressure (18x6mm):
On the nose gear is located the following placard indicating the nose tire inflating pressure (18x6mm):
8.1.17 Doors
Next latch is located a placard that show the correct turn of key for open the door (30x20mm):
