TECO JSDAP Series Simplified Manual

9
dn-08 顯示值
驅動器形式
JSDAP
馬達型號
馬達規格
編碼器規格
Cn030 設定值 功率(KW) 速度(rpm)
H1932
150A3
JSMA-PHH44AH
4.4 2000
8192
H1935 JSMA-PHH44A5 15 bit(ABS)
H1937 JSMA-PHH44A7 17 bit
H193A JSMA-PHH44AA 17 bit(ABS)
H1A12
200A3
JSMA-PMH75AH
7.5
1500
8192
H1A15 JSMA-PMH75A5 15 bit(ABS)
H1A17 JSMA-PMH75A7 17 bit
H1A1A JSMA-PMH75AA 17 bit(ABS)
H1A22 JSMA-PHH55AH
5.5
8192
H1A25 JSMA-PHH55A5 15 bit(ABS)
H1A27 JSMA-PHH55A7 17 bit
H1A2A JSMA-PHH55AA 17 bit(ABS)
H1B12
300A3
JSMA-PMH110AH
11.0
1500
8192
H1B15 JSMA-PMH110A5 15 bit(ABS)
H1B17 JSMA-PMH110A7 17 bit
H1B1A JSMA-PMH110AA 17 bit(ABS)
H1B22 JSMA-PMH150AH
15.0
8192
H1B25 JSMA-PMH150A5 15 bit(ABS)
H1B27 JSMA-PMH150A7 17 bit
H1B2A JSMA-PMH150AA 17 bit(ABS)
H1B32 JSMA-PHH75AH
7.5
8192
H1B35 JSMA-PHH75A5 15 bit(ABS)
H1B37 JSMA-PHH75A7 17 bit
H1B3A JSMA-PHH75AA 17 bit(ABS)
