TECO JSDAP Series Simplified Manual

23
Connection Terminal Servo Drives and Wire Specifications
Connection
Terminal
Position
Number
Position Name
10 15 20 30 50 75 100 150 200 300
14~17
Position Command
Input (Pulse、Sing、
/Pulse、/Sing)
35~40
Encoder Signal
Output
(PA、/PA、PB、/PB、
PZ、/PZ)
41,42
24V Open Collector
Sign Input (EXT1、
EXT2)
CN2
Joint of motor
encoder
1,2
PW Output Terminal
5V (+5E)
0.2mm ² or 0.3mm ² -> Twisted-pair-cable (including shield
cable)
3,4
PW Grounding
Terminal (GND)
5~10
Encoder Signal Input
(A、/A、B、/B、Z、
/
Z
)
CN3
CN4
Communication
connector
1,4,5,7
Data transfer & receiv
e
0.2mm ² or 0.3mm ² -> Twisted-pair-cable (including shield
cable)
3
Communication
grounding wire
2,6,8
Floating
—
P. S. : 1. Please pay attention to the NFB and the capacity of noise filter when using multi Servo Drives.
2. CN1 ->50 Pins (3M Co.).
3. CN2 -> 20 Pins (3M Co.).
4. CN3/CN4-> 8 Pins Mini-Din type.

TECO JSDAP Series Specifications

General

Brand	TECO
Model	JSDAP Series
Category	Servo Drives
Language	English
