System Parameters
Parameter Name & Function Default Unit
Setting
Range
Control
Mode
Communication
Address
RS232 RS485
★
●
Cn001
Control Mode selection
2
X
0
│
A
ALL 510H 0001H
Setting Explanation
0 Torque Control
1 Speed Control
2
External Position Control (external pulse
Command)
3 External Position/Speed Control Switching
4 Speed/Torque Control Switching
5 External Position/Torque Control Switching
6
Internal Position Control (internal position
Command)
7 Internal Position/Speed mode switching
8 Internal Position/Torque mode switching
9 Tool Turret mode
A Internal/External Position switching
★
Cn002.0
SON (Servo On) Input contact function
0 X
0
│
1
ALL
51DH 0002H
Setting Explanation
0 Input Contact, Enables SON (Servo On).
1
Input Contact has no function.
(SON is enabled when Power on).
★
Cn002.1
CCWL & CWL Input contact function.
0 X
0
│
1
Setting Explanation
0
CCWL and CWL input contacts are able to
control the drive inhibit of CCW and CW.
1
CCWL & CWL input contacts are not able to
control CCW and CW drive inhibit. CCW and
CW drive inhibit is disable.
★
Cn002.2
Auto Tuning
0 X
0
│
1
Pi
Pe
S
Setting Explanation
0 Continuously Auto Tuning is Disable
1 Continuously Auto Tuning is Enabled.
★
Cn002.3
EMC reset mode selection
0 X
0
│
1
ALL
Setting Explanation
0
Reset EMC signal is only available in Servo Off
condition (SON contact is open) and reset
AL-09 by ALRS signal.
P.S.) It is NOT allow to reset when SON is
applied.
1
When EMC status is released, AL-09 can be
reset on both Servo ON and Servo OFF
conditions.
Attention!
Ensure that the speed command are removed
before the alarm is reset to avoid motor
unexpected start.
