TECO JSDAP Series Simplified Manual

79
Parameter Name & Function Default Unit
Setting
Range
Control
Mode
Communication
Address
RS232 RS485
Pn482
Internal Position Command 28 -Rotation Number
0 rev
-16000
│
16000
Pi 5D4H 076DH
Please refer to Pn401
Pn483
Internal Position Command 28 - Pulse Number
0 pulse
-131072
│
131072
Pi
5D6H
5D7H
076EH
076FH
Please refer to Pn402
Pn484
Internal Position Command 28 - Move Speed
0 rpm
0
│
6000
Pi 5D5H 0770H
Please refer to Pn403
Pn485
Internal Position Command 29 -Rotation Number
0 rev
-16000
│
16000
Pi 5D8H 0771H
Please refer to Pn401
Pn486
Internal Position Command 29 - Pulse Number
0 pulse
-131072
│
131072
Pi
5DAH
5DBH
0772H
0773H
Please refer to Pn402
Pn487
Internal Position Command 29 - Move Speed
0 rpm
0
│
6000
Pi 5D9H 0774H
Please refer to Pn403
Pn488
Internal Position Command 30 -Rotation Number
0 rev
-16000
│
16000
Pi 5DCH 0775H
Please refer to Pn401
Pn489
Internal Position Command 30 - Pulse Number
0 pulse
-131072
│
131072
Pi
5DEH
5DFH
0776H
0777H
Please refer to Pn402
Pn490
Internal Position Command 30 - Move Speed
0 rpm
0
│
6000
Pi 5DDH 0778H
Please refer to Pn403
Pn491
Internal Position Command 31 -Rotation Number
0 rev
-16000
│
16000
Pi 5E0H 0779H
Please refer to Pn401
Pn492
Internal Position Command 31 - Pulse Number
0 pulse
-131072
│
131072
Pi
5E2H
5E3H
077AH
077BH
Please refer to Pn402
Pn493
Internal Position Command 31 - Move Speed
0 rpm
0
│
6000
Pi 5E1H 077CH
Please refer to Pn403
Pn494
Internal Position Command 32 - Rotation Number
0 rev
-16000
│
16000
Pi 5E4H 077DH
Please refer to Pn401
Pn495
Internal Position Command 32 - Pulse Number
0 pulse
-131072
│
131072
Pi
5E6H
5E7H
077EH
077FH
Please refer to Pn402
Pn496
Internal Position Command 32 - Move Speed
0 rpm
0
│
6000
Pi 5E5H 0780H
Please refer to Pn403
