84
Parameter Name & Function Default Unit
Setting
Range
Control
Mode
Communication
Address
RS232 RS485
Hn617
Digital input control method selection.
H0000 X
H0000
│
H0FFF
(HEX)
ALL C31H 0511H
Select digital input (12 pins) control method by external
terminal or communication. Convert Binary code to Hex
code for setting this parameter. DI and binary bits table as
below.
Ex. DI-1 is bit 0 and DI-12 is bit 12.
DI-[ ] DI-12 ……… DI-1
bit 11 ……… 0
Binary code representation：
￫” 0 “ Digital input control by external terminal.
￫” 1 “ Digital input control by communication.
Set H0000 for Hn617 represent DI-1 ~ DI-12 are controlled
by external terminal and set H0FFF represent all terminal is
controlled by communication.
Ex. Set DI (1, 3, 6, 10, 12) for communication control other
pins by external terminal;
The corresponding binary code is :[0 1010 0010 0101]
convert to Hex code is : [H 0A25]for entering parameter.
For the setting Bit0 (DI-1) is control by communication and
Bit1 (DI-2) is control by external terminal ….etc .
Hn618
Setting digital input status in communication mode
H0000 X
H0000
│
H0FFF
(HEX)
ALL 5FFH 0512H
Change Hn618 Hex code for setting digital input status of
communication control mode; Setting method refer Hn617.
Binary code representation:
“0” : digital input contact OFF
“1” : digital input contact ON
Set H0000 for Hn617 represent DI-1 ~ DI-12 are controlled
by external terminal and set H0FFF represent all terminal is
controlled by communication.
P.S.)This parameter should co-operate with Hn617.
