Chapter 1: Introduction > Using the keypad
Challenger10 Administrators Manual 7
Using the keypad
Use the following steps to access the menu when the “Code” prompt is displayed
on the bottom line of the LCD screen.
In the following example, the system is configured to display the time and date
instead of the default message “There Are No Alarms In This Area”.
14:01 30/08/2012
Code:
1. Press [MENU*].
To Access Menu Enter Code
Code:
2. Press nnnn (where nnnn is your code), and then press [ENTER] to display the
user menu prompt.
“0”-Exit “ENTER”-Down “*”-Up
0-Exit, Menu:
3. From the user menu prompt, you can now select the menu option you need
(see Figure 1 on page 4), or press [0] [ENTER] to exit. Alternatively, press
[ENTER] (or the RAS’s down button, if applicable) to view the available user
menu options in sequence.
4. When finished, press [0] [ENTER] or [CLEAR] to exit the menu.
Note: After a few minutes of inaction, the Challenger system automatically exits
the menu and returns to the “Code” prompt. However, we recommend that you
press [0] [ENTER] or [CLEAR] to exit the menu when you are finished, in order to
prevent unauthorised use (that would otherwise be logged against your code).
The following keys are used to move between menu options:
• Press [ENTER] to scroll forward one menu option.
• Press [MENU*] to scroll backward one menu option.
• Press the menu number and press [ENTER] to jump directly to a menu.
• Press [0] [ENTER] or press [CLEAR] to exit the menu.
To program a value, such as a number or amount, enter the value and press
[ENTER]. The information will be saved. Press [ENTER] to display the next
option.
To program a YES/NO option, press [ENTER] to accept the display or press
[MENU*] to toggle between YES and NO. Press [0] [ENTER] to skip options.
