Chapter 3: Menu reference > Option 1 Panel Status
18 Challenger10 Administrators Manual
Option 1 Panel Status
Use Panel Status to list:
• Inputs in alarm. The input number is preceded by “A”.
• Inputs in tamper alarm. The input number is preceded by “T”.
• Isolated inputs. The input number is preceded by “i”.
• Unsealed inputs. The input number is preceded by “u”.
• System alarms. For example, DGP tamper.
From the User menu prompt (see “Using the keypad” on page 7), press
[1] [ENTER] to display a list of active alarms, tamper alarms, isolated inputs, or
unsealed inputs.
No Alarms, Tampers, Isolates, Unsealed.
Press ENTER
Press [ENTER] to exit this option, or press [NEXT] to update the display.
When one or more inputs are in alarm, tamper alarm, isolated, or unsealed, the
LCD screen displays the most recent alarm. If you see only numbers and no
names, refer to “Displaying input names” on page 8.
Summary On u2, Front Door Contact
NEXT or ENTER
Press [NEXT] or [MENU*] to display additional inputs, if any. Press [ENTER] to
exit the option.
Option 2 Input Unsealed
From the User menu prompt (see “Using the keypad” on page 7), press
[2] [ENTER] to display a list of unsealed inputs (for example, an open door
contact). The LCD screen displays the following information when no inputs are
unsealed.
All Inputs are Sealed.
Press ENTER
Note: If the system is configured for input tamper monitoring (four-state
monitoring), open circuit and short circuit conditions are also displayed.
Press [ENTER] to exit this option, or press [NEXT] to update the display.
When one or more inputs are unsealed, the LCD screen displays the inputs. If
you see only numbers and no names, refer to “Displaying input names”
on page 8. The input number is preceded by A if the unsealed input is in alarm,
or T if in tamper.
