www.tecsunradios.com.au
PL-660...................................................................................15
When the preset alarm is activated, you can press the
[LIGHT/SNOOZE] button with “ ” or “ ” flashing in order to turn
off the alarm temporarily, but the unit will turn on again after 5
minutes later.
Notes:
1. You can press the [TIMER A] or [TIMER B] button repeatedly to
turn on/off the alarm by radio.
If the symbol shows on the display, it means the
alarm by radio was activated, otherwise, it isn’t activeated.
2. If the preset alarm is activated, press the [POWER] button once to
continuously listen to the radio; press it twice to turn off the radio.
3. If the preset alarm is activated when you are listening to the radio,
it will auto switch to the preset alarm station.
“ ” or “ ”
SNOOZE FUNCTION
A
B
A
B
This radio has an intelligent lighting function with which the backlight
would be on for 3 seconds when operating any keys or knobs.
TURN ON/OFF THE BACKLIGHT:
Press the [LIGHT/SNOOZE] button to illuminate the LCD for 3
seconds; press & hold the [LIGHT/SNOOZE] button for permanently
illumination. Press it again to turn off the backlight.
Notes:
1. When the unit is powered by the battery, please try to avoid
setting the backlight to permanent illumination so as to reduce
power consumption.
2. When the unit is turned off, the permanent illumination function
will be turned off automatically as well.
INTELLIGENT LIGHT FUNCTION

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Tecsun PL-660 and is the answer not in the manual?

Tecsun PL-660 Specifications

Frequency Range IconFrequency Range
FM frequency range76~108 / 87~108 MHz
MW frequency range522~1620 / 520~1710 kHz
LW frequency range100~519 kHz
SW frequency range1711~29999 kHz
AIR frequency range118~137 MHz
Sensitivity IconSensitivity
FM sensitivityLess than 3 uV
MW sensitivityLess than 1 mV/m
LW sensitivityLess than 5 mV/m
SW sensitivityLess than 20 uV
SSB sensitivityLess than 1 uV
AIR sensitivityLess than 5 uV
Selectivity and S/N Ratio IconSelectivity and S/N Ratio
FM selectivity> 30 dB (±200 kHz)
MW/LW selectivity> 40 dB (±9 kHz)
SW selectivity> 40 dB (±5 kHz)
FM S/N ratioLess than 60 dB
MW/LW S/N ratioLess than 45 dB
SW S/N ratioLess than 50 dB
AM Frequency IconAM Frequency
SSB, AM 1st IF55.845 MHz
AM 2nd IF455 kHz
FM IF10.7 MHz
Output Power IconOutput Power
Speaker output power≥ 450 mW
Earphone output power≥ 10 mW
FM Stereo crosstalkLess than 20 dB
