7
As the fins of the evaporator are very sharp. always wear protective gloves for the next phases .Only
a brush must be used for cleaning :do not use jets of liquid or sharp instruments.
To access the evaporator proceed as follows:
1. Open the door(A) of the appliance.
2. Loosen the two screws (B)on the right of the deflector.
3. Remove the runners(C)
4. Turn the deflector(D) to the left.
Clean the condenser
Clean the condenser periodically
As the fins of the condenser are very sharp, always wear protective gloves for the next phases. Use
protective masks and glasses in the presence of dust
Whenever the condenser has a deposit of dust in correspondence with the fins, this can be removed
using a suction device or with a brush applied, using a vertical movement along the direction of the fins.
No other instruments must be used, which may deform the fins and therefore the efficiency of the
appliance.
To clean, proceed as follows:
1. Open the door (A) of the appliances.
2. Remove the lower panel(B) from the technical compartment: to do this, remove the screw
fasteners(C)
3. It is now possible to clean the finned part of the condenser (D) using suitable tools and protection
devices.
4. After cleaning, close the control panel and fix it with the screws removed beforehand.
