13 of 28 © 2009 D 527 - 06/09
Display Range Description
OFF, 40 to 85°F
(OFF, 4.5 to
29.5°C)
Default = 72°F
(22.0°C)
SET FLOOR
Set the floor temperature while in the event.
Available when:
Room Sensor setting in the Adjust menu is set to Off AND
A slab sensor is installed on the auxiliary sensor input AND
Switch setting 4 is set to Floor (On position).
•
•
•
OFF, 40 to 85°F
(OFF, 4.5 to
29.5°C)
Default = 68°F
(20.0°C)
SET FLOOR
Set the floor temperature while in the event.
Available when:
Room Sensor setting in the Adjust menu is set to Off AND
A slab sensor is installed on the auxiliary sensor input AND
Switch setting 4 is set to Floor (On position).
•
•
•
On, OFF
Default = On
ROOM SENSOR
Select whether the built-in air temperature sensor is on or off.
When set to off, a floor sensor is required.
Available when:
Switch setting 4 is set to Floor (On position).•
Auto, SYn
Default = Auto
HEAT CYCLES PER HOUR
Select either Auto cycle or Synchronize with other thermostats
on the tekmarNet
®
system.
Available when:
There is no tekmarNet
®
System Control in the system.•
OFF, On
Default = OFF
THERMAL MOTOR DELAY
Select whether or not a thermal motor (wax actuator) zone valve
is operated.
Available when:
There is a tekmarNet
®
System Control in the system.•
1, 2, 3, 4
Default = 1
SCHEDULE
Thermostat can follow schedule 1, 2, 3, or 4.
Available when:
Switch setting 1 is set to Setback (On Position).•
Adjust Menu (2 of 2) *for installer use only
ADJUST MENU
After the last item, the control returns to the first item in the Adjust menu.
528 Thermostat
