© 2009 D 527 - 06/09 8 of 28
Display Description
STEP 1
Change the Non-current
Temperature
After pressing the and buttons simultaneously, the non-current
temperature setting will show on the display.
Press the or button to change the non-current temperature.
Current Temperature Non-current Temperature
The Away temperature is fixed at 62°F and is not adjustable.
Note: If switch setting 1 (setback) and switch setting 2 (scenes) are both
off, then the non-current temperature adjustment is not available.
STEP 2
°F or °C
Press the or the button to change from °F to °C and vice versa.
STEP 3
Backlight
Off, 30 sec, On
Press the or the button to select the backlight to permanent Off,
30 second temporary on, or permanent On.
STEP 4
Auto cycle or
Synchronization
Press the or the button to select between Auto cycles or
Synchronization.
Available when:
• There is no tekmarNet
®
System Control on the system.
STEP 5
View Type and Software
Version
The large number shows the type number as 527.
The software version is shown in the upper right hand corner.
STEP 6
View tekmarNet
®
Address
The thermostat’s tekmarNet
®
address is shown.
The address toggles between a number and “Au” when using automatic
addressing.
STEP 7
Manually Change
tekmarNet
®
Address
Press the or the button to manually select an address.
The address can be returned to automatic “Au” between addresses
24 and 1.
Ensure to document the address number when manually addressing
thermostats.
User Settings (1 of 1)
Press and hold down both the and buttons to change from one step to the next. While
holding both buttons down, a new setting will display every 5 seconds.
Release both buttons once the step has been reached.
Press the or the button to change the setting, if available.
Press and hold down both the and buttons for 5 seconds to go to the next step, OR
After 10 seconds of no button activity, the display goes back to normal operation.
•
•
•
•
•
Press
+
Together
To change settings other than the current temperature, use the following steps:
527 Thermostat
