DVR XP Woodlathe Specifications
Size: 1100mm(L) x 240mm (W) x 412mm(H)
43 1/3"(L) x 9 1/2" (W) x 16 1/4"(H)
Weight: 82kg (181 LB)
Swing Over Bed: 400mm (16in.)
Distance Between Centers: 600mm (24in.);
extendable in 510mm (20in.) units with
add-on Bed sections.
Swing Outboard: 740mm (29in.) with headstock
at 90° using outrigger toolrest.
Headstock:
Spindle Thread: M33 x 3.5 RH
(1)
or
1-1/4 x 8 TPI RH
(2)
Headstock Bore: No. 2 Morse Taper (#2 MT)
Headstock Swivel: 0 to 360 degrees, with
detents at 0, 22.5, 45, and 90 degrees.
Outboard End Internal Thread: M20 x 1.5 LH
Spindle Index: 24 divisions (every 15 degrees) 15mm
through-hole through Headstock
Tailstock:
Tailstock Bore: No. 2 Morse Taper (#2 MT)
Quill Travel: 85mm (3-1/4in.)
Hole Through Tailstock: 15mm (9/16in.)
Toolrest:
Length: 300mm (12in.)
Shaft Diameter: 25.4mm (1in.)
Speeds (rpm):
100 – 3500 (in 5rpm increments)
Favourite Speeds:
5 presets
Standard Equipment:
300mm (12in.) Toolrest, 80mm (3in.) Faceplate* (Not
all countries, see notes below), (Not all countries, see
notes below) Spur Center, and Live Center. Outboard
Handwheel.
Nova 3000 Bowl Lathe Version:
Specifically for bowl turning, does not include bed
extension, tailstock, and centers.
Optional Accessories:
Precision Midi, G3, SuperNova 2 & Titan Chuck
80mm (3in.) Faceplate
Vacuum Faceplate
100mm (4in.) Toolrest
Bowl Toolrest
Outrigger Toolrest Unit
Vacuum Coupler
Revolving Center System
Faceplate rings
Notes:
(1) Applicable to Europe (excluding the UK)
(2) Applicable to United States, Canada, United Kingdom,
Australia, New Zealand & South Africa.
* Note: Standard equipment varies from country to country, In
some markets, the faceplate is an optional accessory. Check with
your reseller if you are unsure.
For Europe, Australasia, UK and South Africa
Directives this equipment complies with:
Low voltage directive (LVD) 73/23/EEC + 93/68/EEC +2006/95/EC
Machinery directive (MD) 89/392/EEC + 91/368 EEC + 93/68/EEC +
2006/42/EC Electromagnetic compatibility directive (EMCD)
89/336/EEC + 92/31/EEC + 93/68/EEC + 2004/108/EC
Harmonized Standards applied in order to verify compliance with
Directives:
EN 61029-1:2009 (Low Voltage Directive and Machinery
Directive)
EN 55014-1:2007
EN 55014-2:2009
EN 61000-3-2: Ed3 2006
EN 61000-3-3:1995 A1 + A2
Signed………………………………………..Dated 10/12/2010
Nathan Stantiall
Development Manager
