Appendix A: Specifications
370B User Manual
A-15
Table A-10: Power Supply
Characteristic Performance Requirement Operating Information
Rating Voltage 115 VAC / 230 VAC
Line voltage range
115 VAC High 107 VAC to 132 VAC
Low 90 VAC to 110 VAC
230 VAC High 214 VAC to 250 VAC
Low 180 VAC to 220 VAC
Frequency Range 48.0 Hz to 63.0 Hz
Power Consumption Max. 400 W, 3.5 A
Typical 120 W, 1.3 A at 115 V, 50 Hz
Fuse
115 VAC 125 V, 4 A, FastĆBlow
230 VAC 250 V, 2 A, FastĆBlow
Table A-11: Surge Current
Characteristic Description
Surge Current
80 A peak (25_C) for x 5 line cycles, after product has been turned off for at least 30 S.
