4-32
370B User Manual
Table 4-9: Front Panel Controls
DISPLAY COMMAND GROUP
Command Argument Link Definition
DISPLAY NSTore Selects NON STORE mode.
STOre Selects STORE mode.
VIEw <NR1> Selects VIEW mode.
DISPLAY VIEW:<index>
<index> ::= 1|2|...|80
REF ON
OFF
Displays REF curve.
Turns off the REF curve display.
INVert ON
OFF
Selects display invert mode.
Disables display invert mode.
CAL ZERo
OFF
FULl
Sets the CRT check mode.
DISPLAY? Response with display data:
DISPLAY <mode1>, <mode2>, <mode3>, <mode4>
<mode1> ::= INVERT:OFF|
INVERT:ON
<mode2> ::= CAL:ZERO|
CAL:OFF|
CAL:FULL
<mode3> ::= NSTORE|STORE|
VIEW:<NR1>
<mode4> ::= REF:ON|
REF:OFF
ENTer <NR1> Store the displayed curve data in the memory location specified by the
argument.
ENTER <index>
<index> ::= 1|2|...|80
VERt STEp
COLlect <NRX>
Selects vertical source and amps/div.
Requires an NRĆ13 type number for amps/div.
Will return NR3 in query form.
VERT <source> [:<amp>]
Current ranges allowed:
COLLECT <amp> ::= {1.0E-6 - 2.0E+0}
(COLLECTOR POLARITY not leakage mode)
COLLECT <amp> ::= {1.0E-9 - 2.0 E-3}
(COLLECT POLARITY leakage mode)
OFFset <NR2> Sets vertical display offset
VERT OFFSET :<val>
<val> ::= +/- 10.0 by 0.1
