Tektronix 370B User Manual

GPIB
370B User Manual
4-33
Table 4-9: Front Panel Controls (Cont.)
Command DefinitionLinkArgument
VERt? Response with the vertical source, amps/div, and display offset.
VERT <source> [:<amp>],
OFFSET :<val>
<source> ::= STEP|COLLECT
<amp> := amps/div (NR3)
<val> := display offset value
HORiz STEp
COLlect
BASe
<NRX>
<NRX>
Selects the horizontal source and volts/div.
Use a NR1-3 type number of volt/div.
Returns NR3 in query form.
HORIZ <source> [:<volt>]
Voltage ranges allowed:
COLLECT <volt> ::= {5.0E-2 - 5.0E+2}
BASE <volt> ::= {5.0 E-2 - 5.0E+0}
OFFSet <NR2> Sets horizontal display offset.
HORIZ OFFSET :<val>
<val> ::= +/- 10.0 by 0.1
HORiz? Response with the horizontal source, volts/div, and display offset.
HOriz <source> [:<volt>],
OFFSET :<val>
<source> ::= STEP|COLLECT:BASE
<volt> := volts/div (NR3)
<val> := display offset value
CURSOR CONTROL COMMAND GROUP
CURSor OFF Currently displayed cursor disappears.
CURSOR OFF
DOT <NR1> Sets the DOT cursor on the specified curve data position.
DOT <data>
<data> ::= curve data position
{1 - 1024}
DOT? Response with the Dot cursor position:
DOT <NR1>
LINe <NR1>, <NR1> Sets the f Line cursor intercept position on the display.
LINE <data1>, <data2>
<data1> :== horizontal position
{0 - 1000}
<data2> :== vertical position
{0 - 1000}
LINe? Response with the f LINE cursor intercept position:
LINE <NR1>, <Nr 2>
