GPIB
4-34
370B User Manual
Table 4-9: Front Panel Controls (Cont.)
Command DefinitionLinkArgument
WINdow <NR1>
<NR1>
<NR1>
<NR1>
Sets the Window cursor to the specified position on the CRT.
WINDOW <data1>, <data2>, <data3>, <data4>
<data1> ::= Lower-left horizontal
{0 - 1000}
<data2> ::= Lower-left vertical
{0 - 1000}
<data3> ::= Upper Ćright horizontal.
{0 - 1000}
<data4> ::= Upper-right vertical
{0 - 1000}
WINdow? Response with the Window position:
WINDOW <NR1>, <NR1>, <NR1>, <NR1>
COLLECTOR SUPPLY CONTROL COMMAND GROUP
PKVolt 16
80
400
2000
Sets maximum peak volts:
PKVOLT <set>
<set> ::= 16|80|400|2000
PKVolt? Response with maximum peak volts:
PKVOLT <set>
<set> ::= 16|80|400|2000
PKPower 220.0
50.0
10.0
2.0
0.08
Sets max peak power in the watts.
PKPOWER <set>
<set> ::= 220.0|50.0|10.0|2.0|0.4|0.08
PKPower? Response with max peak watts:
PKPOWER <set>
<set> ::= 220.0|50.0|10.0|2.0|0.4|0.08
CSPol PLEakage
PDC
PNOrmal
AC
NNOrmal
NDC
NLEakage
Selects collector supply polarity and mode.
CSPOL <mode>
<mode> ::= PLE|PDC|PNO|AC|NNO|NDC|NLE
PLE ::= +LEAKAGE,
PDC ::= +DC,
PNO ::= +(fullwave),
AC ::= AC,
NNO ::= -DC,
NLE ::= -LEAKAGE
CSPol? Reports collector supply polarity and mode:
CSPOL <mode>
<mode> ::= PLEAKAGE|PDC|PNORMAL|AC|NNORMAL|
NDC|NLEAKAGE
