Operating Basics
2-28
370B User Manual
Figure 2–11 shows the Readout Display.


  
 
  
  
 
Figure 2-11: Readout Display
The 370B CRT has an internal printed graticule and characters (VERT/DIV.
HORIZ/DIV, etc.) for internal setups.
GRAT ILLUM controls the brightness of the graticule and printed characters.
Figure 2–11 illustrates the screen readout areas. The types of readout information
are:
 Setup Readout
 Text Error Message
 Curve/Setup ID
 Display Offset
 Average Count
 AUX Supply Voltage
