Appendix A: Specifications
370B User Manual
A-17
Functional Specification
Table A-13: Digital Storage Acquisition Mode
Characteristic Performance Requirement Operating Information
Normal Acquires and displayed each curve.
Envelope
Vertical Envelope Acquires and displays the maximum and
minimum vertical excursion of each curve.
Horizontal Envelope Acquires and displays the maximum and
minimum horizontal excursion of each curve.
Averaging Acquires and displays the average of last 16
acquisitions.
Table A-14: Text Display
Characteristic Performance Requirement Operating Information
Alphanumeric character
Set (1)
ASCII character set except double quote ("),
u is recognized as m)
GPIBĆaccessible with the TEXT command.
Alphanumeric character
Set (2)
A,B,....,Y,Z,(Space),m, u,
n,o,,,0,........,9,-,*,(,),
Accessible with the Position Control buttons.
Maximum text string length 24 characters
Character size Approximately 3 mm height, 2 mm width.
