Appendix C: Diagnostic Routines and Messages
370B User Manual
C-5
Table C-2: Front Panel Control Identification (Cont.)
Control Message
CONFIGURATION up CONFIGURATION up
CONFIGURATION down CONFIGURATION down
LEFT LEFT
STANDBY STANDBY
RIGHT RIGHT
INTERLOCK COVER ON
COVER OFF
VERTICAL CURRENT/DIV VERTICAL XX (0 - 16)
HORIZONTAL VOLTS/DIV HORIZONTAL XX (0 - 16)
STEP AMPLITUDE STEP AMP XX (0 - 16)
VARIABLE COLLECTOR SUPPLY VARIABLE XX (0 - 16)
OUTPUTS OUTPUT ENABLE
OUTPUT DISABLE
PROTECTIVE COVER COVER ON
COVER OFF
The GPIB TEST? command initiates the 370B system ROMs and RAMs
diagnostic routine. The 370B responds to this command by returning system
ROM and RAM information to the controller as follows:
TEST ROM:000X, RAM:YYYY
GPIB Diagnostic Routine
