Troubleshooting
Table 4-7: Calibration error codes (cont.)
Error code Error log message
Possible defect
on board Note
261000200
Waveform write error AWG12G AWG12G:U1000, U400A/B,
U500A/B, U510A/B
261001001
Invalid NG Areas. (ch1_ram_address_timing@12GHz) AWG12G
261001002
Invalid NG Areas. (ch2_ram_address_timing@12GHz) AWG12G
261001003
Invalid NG Areas. (ch1_ram_address_timing@10GHz) AWG12G
261001004
Invalid NG Areas. (ch2_ram_address_timing@10GHz) AWG12G
262000011
The Cal value is not found. (ch1_pld_timing_1@12GHz) AWG12G AWG12G:U300A, U400A
262000012
The Cal value is not found. (ch2_pld_timing_1@12GHz) AWG12G AWG12G:U300B, U400B
262000013
The Cal value is not found. (ch1_pld_timing_2@10GHz) AWG12G AWG12G:U300A, U400A
262000014
The Cal value is not found. (ch2_pld_timing_2@10GHz) AWG12G AWG12G:U300B, U400B
262000015
The Cal value is not found. (ch1_pld_timing_3@12GHz) AWG12G AWG12G:U300A, U400A
262000016
The Cal value is not found. (ch2_pld_timing_3@12GHz) AWG12G AWG12G:U300B, U400B
262000017
Temperature changed 5 degrees or more.(@PLD
Timing Cal.)
AWG12G
Ambient temperature
262000111
The difference of ch1_pld_timing_1 and
ch2_pld_timing_1 is larger than 24.(@12G Hz)
AWG12G AWG12G:U300A/B, U400A/B
262000113
The difference of ch1_pld_timing_2 and
ch2_pld_timing_2 is larger than 24.(@10G Hz)
AWG12G AWG12G:U300A/B, U400A/B
262000115
The difference of ch1_pld_timing_3 and
ch2_pld_timing_3 is larger than 24.(@12G Hz)
AWG12G AWG12G:U300A/B, U400A/B
262001005
Invalid NG Areas. (ch1_pld_timing@12GHz) AWG12G AWG12G:U300A,U400A
262001006
Invalid NG Areas. (ch2_pld_timing@12GHz) AWG12G AWG12G:U300B,U400B
262001007
Invalid NG Areas. (ch1_pld_timing@10GHz) AWG12G AWG12G:U300A,U400A
262001008
Invalid NG Areas. (ch2_pld_timing@10GHz) AWG12G AWG12G:U300B,U400B
263000025 tek15_ch1_k is not 6, 7 or 8.
AWG12G AWG12G:U100A, U300A
263000026 tek15_ch2_k is not 6, 7 or 8.
AWG12G AWG12G:U100B, U300B
263000027
The C al value is not found. (tek15_ch1_ng_f) AWG12G AWG12G:U100A, U300A
263000028
The C al value is not found. (tek15_ch2_ng_f) AWG12G AWG12G:U100B, U300B
263000029 Temperature changes 5 degrees or more during
MagicCal.
AWG12G
Ambient temperature
263000031
Set end point before start point. Or too large delay was
set as reference delay (CH1).
AWG12G AWG12G:U100A,U300A
263000032
Set end point before start point. Or too large delay was
set as reference delay (CH2).
AWG12G AWG12G:U100B, U300B
263000125 tek15_ch1_k and tek15_ch2_k are not equal.
AWG12G AWG12G:U100A/B,U300A/B
263001106
Temperature changes 5 degrees or more from PLD
timing Cal.
AWG12G
Ambient temperature
AWG7000B and AWG7000C Series Service Manual 4–69
