Maintenance
This section contains information needed to do periodic and corrective
maintenance on the instrument. The following subsections are included:
Preparation – Tells you how to prepare for arbitrary waveform generator
maintenance.
Preparation Preventing ESD – Provides general information on preventing
damage to internal modules when doing maintenance.
Inspection and Cleaning – Information and procedures for inspecting the
instrument and cleaning its external and internal modules.
Removal and Installation Procedures – Procedures for the removal o f
defective modules an
d installation of new or repaired modules.
Troubleshooting – Information for isolating failed modules. Included
are instructions for operating the instrument diagnostic routines and
troubleshooting trees. Most of the trees make use of the internal diagnostic
routines to speed fault isolation to a module.
Preparation
Only qualified persons should perform service procedures. Before performing any
service procedures, read the Service Safety Summary and G eneral Safety Summary
at the front of this manual and the ESD information b elow. Also refer to the
Operating Information section and your arbitrary waveform generator quick start
user manual for information about using the arbitrary waveform generator.
Preventing ESD
When performing any service that r equires internal access to this instrument,
adhere to the following precautions to avoid damaging internal modules and their
components due to electrostatic disch
arge (ESD).
CAUTION. Static discharge can damage any semiconductor component in this
instrument.
Minimize handling of static-sensitive modules.
Transport and store static-sensitive modules in their static protected containers
or on a metal rail. Label any package that contains static-sensitive modules.
Discharge the static voltage from your body by wearing a grounded antistatic
wrist strap while handling these modules. Service static-sensitive modules
only at a static-free work station.
AWG7000B and AWG7000C Series Service Manual 4–1
