Saving and Recal
ling Setups
Exporting Waveform Data
The arbitrary waveform generator can export w aveform data to a text file for use with other applications. You can also select
a pattern file or waveform file for use in AWG400/500/600/700 series instruments.
1. Select the waveform data for export.
You can select a waveform from the
Waveform List window.
2. Right click to display the popup menu.
Select Export Waveform to File to open
the dialog box.
You can also select the Export Waveform
to File dialog box by right-clicking in the
Sequence or Waveform window.
3. This is a
n example of a dialog box when
you export a Real format waveform in an
AWG7000 series instrument.
4. Select a file format.
5. You can export a Real format
wavefo
rm into a *.wfm file for
the AWG400/500/600/700 series
instruments.
48 AWG5000 and AWG7000 Series Quick Start User Manual
