Troubleshooting
Table 4-8: Hardware error codes (cont.)
Error code Error log message
Possible defect
on board N ote
300000104
Access to EEPROM failed on AWG board. AWG12G AWG12G: U1090
300000200
The download (MIO-INIT) timeout period has
expired.
MIO MIO: U 200, U300
300000201
The download (MIO-INIT) timeout period has
expired.
MIO MIO: U 200, U300
300000202
The download (MIO-DONE) timeout period has
expired.
MIO MIO: U 200, U300
300000203
The download (MIO) timeout period has expired. MIO MIO: U 200, U300
300000204
The system cannot find the file
specified.(PLD140b.Bit)
N/A Software
300000205 An attempt was made to load a program with an
incorrect format.(PLD131.Bit)
N/A Software
300000206
The download(AwgController-INIT) timeout period
has expired.
MIO, AWG12G MIO: U300 AWG12G: U1000
MIO-AWG12G Cable
300000207
The download(AwgController-INIT) timeout period
has expired.
MIO, AWG12G MIO: U300 AWG12G: U1000
300000208
The download(AwgController-DONE) timeout
period has expired.
MIO, AWG12G MIO: U300 AWG12G: U1000
MIO-AWG12G Cable
300000209
The download (AwgController) timeout period has
expired.
MIO, AWG12G MIO: U300 AWG12G: U1000
MIO-AWG12G Cable
300000210
The system cannot find the file
specified.(PLD231.Bit)
N/A Software/Disk Drive
300000211 An attempt was made to load a program with an
incorrect format.(PLD231.Bit)
N/A Software/Disk Drive
300000212
The download (MemoryController-INIT) timeout
period has expired.
MIO, AWG12G MIO: U300 AWG12G: U1000, U400xx
300000213
The download (MemoryController-INIT) timeout
period has expired.
MIO, AWG12G MIO: U300 AWG12G: U1000, U400xx
300000214
The download (MemoryController-DONE) timeout
period has expired.
MIO, AWG12G MIO: U300 AWG12G: U1000, U400xx
300000215
The download (MemoryController) timeout period
has expired.
MIO, AWG12G MIO: U300 AWG12G: U1000, U400xx
300000216
The system cannot find the file
specified.(PLD230b.Bit)
N/A Software/Disk Drive
300000217 An attempt was made to load a program with an
incorrect format.(PLD230b.Bit)
N/A Software/Disk Drive
300000218
The DCM timeout period has expired. MIO MIO: U300
300000219
The LO CK ED timeout period has expired. MIO MIO: U300
300000220
A PLD231.Bit file is old version. N/A Software/Disk Drive
300000221
A PLD230.Bit file is old version. N/A Software/Disk Drive
4–74 AWG7000B and AWG7000C Series Service Manual
