Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-11: Delta time measureme nt settings (cont.)
Instrument Volts/div
Sine wave
generator
frequency
Record
length
Sample
rate
Burst
width
Delta time rms
accuracy limit
Delta time
pk-pk
accuracy limit
BWE on
50 mV
11.2 GHz
10000
500 GS/s
10 ns 1.260 ps 12.60 ps
MSO72004C and
DPO72004C, 20 GHz
100 mV
11.2 GHz
10000
500 GS/s
10 ns 1.432 ps 14.32 ps
10 mV
11.2 GHz
10000
500 GS/s
10 ns 1.336 ps 13.36 ps
50 mV
11.2 GHz
10000
500 GS/s
10 ns 1.182 ps 11.82 ps
MSO72004C and
DPO72004C, 18 GHz
100 mV
11.2 GHz
10000
500 GS/s
10 ns 1.234 ps 12.34 ps
10 mV
9.94 GHz
10000
500 GS/s
10 ns 1.219 ps 12.19 ps
50 mV
9.94 GHz
10000
500 GS/s
10 ns 1.154 ps 11.54 ps
MSO71604C and
DPO71604C, 16 GHz
100 mV
9.94 GHz
10000
500 GS/s
10 ns 1.159 ps 11.59 ps
10 mV
7.45 GHz
10000
500 GS/s
10 ns 1.333 ps 13.33 ps
50 mV
7.45 GHz
10000
500 GS/s
10 ns 1.212 ps 12.12 ps
MSO71254C and
DPO71254C, 12.5 GHz
100 mV
7.45 GHz
10000
500 GS/s
10 ns 1.228 ps 12.28 ps
10 mV
4.97 GHz
10000
500 GS/s
10 ns 1.354 ps 13.54 ps
50 mV
4.97 GHz
10000
500 GS/s
10 ns 1.235 ps 12.35 ps
MSO70804 and
DPO70804B, 8 GHz
100 mV
4.97 GHz
10000
500 GS/s
10 ns 1.241 ps 12.41 ps
10 mV
3.73 GHz
10000
500 GS/s
10 ns 1.445 ps 14.45 ps
50 mV
3.73 GHz
10000
500 GS/s
10 ns 1.295 ps 12.95 ps
MSO70604 and
DPO70604B, 6 GHz
100 mV
3.73 GHz
10000
500 GS/s
10 ns 1.329 ps 13.29 ps
10 mV
2.48 GHz
10000
500 GS/s
10 ns 1.674 ps 16.74 ps
50 mV
2.48 GHz
10000
500 GS/s
10 ns 1.437 ps 14.37 ps
MSO70404 and
DPO70404B, 4 GHz
100 mV
2.48 GHz
10000
500 GS/s
10 ns 1.478 ps 14.78 ps
Adjust the g enerator output as necessary to obtain 8 divisions of
displayed waveform.
d. Set up for statistics measurements:
From the button bar, touch Measure and select the More tabtoshow
the More Measurements menu.
Touch the Burst Width button.
Touch Setups Gating andthentouchCursor.
Touch Setup.
Touch Setups Statistics and then touch All.SettheWeightn=to1000.
Touch Reset to reset the statistics.
Touch Setup.
Touch Setups Ref Levs and then touch Absolute.
