Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical s pecifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.
)
Characteri
stic
Descriptio
n
MSO/DSA/DP
O72004C,
MSO/DSA/DPO71604C
DC >12.5 GHz
,typical
MSO/DSA/DPO71254C DC >11 GHz, typical
MSO70804, DSA/DPO70804B DC >8 GHz, typical
MSO70604, DSA/DPO70604B DC >6 GHz, typical
Analog bandwidth, with P7313
active prob
e,
≥ 4 GHz models
MSO70404, DSA/DPO70404B DC >4 GHz, typical
Analog bandwidth, 50 Ω DC
coupled,
<4 GHz models
Full bandwidth, operating ambient of ≤ 30 °C (86 °F), derated by 1% for each °C above
30 °C (86 °F)
Note: T
he DPO7354 is guaranteed 3.5 GHz bandwidth with BWE On and can be verified with a
4-division sine wave. Typical bandwidth when measured with an 8-division sine wave is 3 GHz.
Instr
ument
SCALE range
Bandw
idth
10 mV/div to 1 V/div DC to 3.5 GH z, BW E on
DC to 2.5 GHz, BWE off
5 mV/div to 9.99 mV/div DC to 2.0 GHz
2 mV/div to 4.99 mV/div DC to 500 MHz, typical
DPO7354
1 mV/div to 1.99 mV/div DC to 200 MHz, typical
10 mV/div to 1 V/div DC to 2.5 GHz
5 mV/div to 9.99 mV/div DC to 2.0 GHz
2 mV/div to 4.99 mV/div DC to 500 MHz, typical
DPO7254
1 mV/div to 1.99 mV/div DC to 200 MHz, typical
5 mV/div to 1 V/div DC to 1.0 GHz
2 mV/div to 4.99 mV/div DC to 500 MHz, typical
DPO7104
1 mV/div to 1.99 mV/div DC to 200 MHz, typical
5 mV/div to 1 V/div DC to 500 MHz
2 mV/div to 4.99 mV/div DC to 400 MHz, typical
DPO7054
1 mV/div to 1.99 mV/div DC to 200 MHz, typical
Full bandwidth, operating ambient temperature of ≤ 30 °C (86 °F), derated by 1% for each °C
above 30 °C (86 °F)
SCALE range
Bandwidth
5 mV/div to 10 V/div DC to 500 MHz, typical
2 mV/div to 4.98 mV/div DC to 350 MHz, typical
Analog bandwidth, 1 MΩ DC
coupled,
< 4 G Hz models
1 mV/div to 1.99 mV/div DC to 175 MHz, typical
1–8 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
