Tektronix DPO70000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.
)
Characteri
stic
Descriptio
n
Full bandwi
dth, operating ambient of ≤ 30 °C (86 °F), derated by 1% for each °C above
30 °C (86 °F)
SCALE range
Bandwidth
≥ 100 mV/div DC to 2.5 GHz
50 mV/div to 99.5 mV/div DC to 2.0 GHz
20 mV/div to 49.8 mV/div DC to 500 MHz
Analog bandwidth with
TAP2500 VPI
probe, typical,
DPO7254
10 mV/div to 19.9 mV/div DC to 200 MHz
Full bandwidth, operating ambient of ≤ 30 °C (86 ° F), derated by 1% for each °C above
30 °C (86 °F)
SCALE range
Bandwidth
5 mV/div to 10 V/div DC to 500 MHz
2 mV/div to 4.98 mV /div DC to 300 MHz
Analog
bandwidth with X10
passive probe, typical,
< 4 GHz models
1 mV/div to 1.99 mV /div DC to 175 MHz
Analog bandwidth selections,
< 4 GHz models
20 MHz, 250 MHz, and Full
Lower frequency limit, AC coupled,
<4
GHz models
10 Hz when 1 MΩ, AC coupled. The limit is reduced by a factor of 10 when 10X, passive
pr
obes are used.
U
pper frequency limit, 250 MHz
bandwidth limited,
< 4 GHz models
250 MHz
Upper frequency limit, 20 M Hz
bandwidth limited,
< 4 GHz models
20 MHz
Passband flatness, BWE, typical Use the Temperature variation table to determine the amount of performance derating above
the temperature limit.
Step settings
Temperature
constraint
100 mVFS, 200 mVFS, 500 m VFS, 1 VFS, and
2.5 VFS
± 0.5 dB from DC to 50% of nominal bandwidth.
± 1.5 dB from 50% to 80% of nominal bandwidth.
Non-step settings
MSO/DSA/DPO72004C,
MSO/DSA/DPO71604C,
MSO/DSA/DPO71254C
± 1.0 dB from DC to 50% of nominal bandwidth
± 2.0 dB from 50% to 80% of nominal bandwidth.
At 25 °C
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 1–9
