Tektronix DPO70000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.
)
20 GS/s
Step gain 3.5 G Hz 3.0 GHz 2.5 GHz 2.0 GHz 1.0 GHz 0.5 GHz
500 mV 24.3 mV 21.6 mV 19.1 mV 16.7 mV 12.4 mV 9.9 mV
200 mV 11.1 mV 9.3 mV 8.4 mV 7.1 mV 5.35 mV 4.2 mV
100 mV 6.65 mV 5.5 mV 4.95 mV 4.25 mV 3.1 mV 2.4 mV
50 mV 2.45 mV 2.2 mV 1.95 mV 1.8 mV 1.35 mV 1.1 mV
20 mV 1.055 mV 0.93 mV 0.83 mV 0.75 mV 0.55 mV 0.435 mV
10 mV 0.625 mV 0.55 mV 0.475 mV 0.425 mV 0.31 mV 0.24 mV
5 mV 0.415 mV 0.415 0.415 mV 0.415 mV 0.215 mV 0.16 mV
2 mV 0.19 mV 0.19 mV 0.19 mV 0.19 mV 0.185 mV 0.185 mV
1 mV 0.12 mV 0.12 mV 0.12 mV 0.12 mV 0.12 mV 0.12 mV
10 GS/
s
Step g
ain
3.5 G H
z
3.0 GH
z
2.5 GH
z
2.0 GH
z
1.0 GH
z
0.5 G H
z
500 mV 25.8 mV 22.2 mV 20.0 mV 17.7 mV 13.2 mV 10.4 mV
200 mV 11.7 mV 9.9 mV 8.7 mV 7.5 mV 5.5 mV 4.3 mV
100 m
V
6.9 m
V
5.6 m
V
5.0 m
V
4.3 m
V
3.2 m
V
2.4 m
V
50 mV 2.6 mV 2.3 mV 2.05 mV 1.85 mV 1.4 mV 1.15 mV
20 mV 1.11 mV 0.99 mV 0.87 mV 0.77 mV 0.58 mV 0.45 mV
10 m
V
0.6
5mV
0.5
5mV
0.4
9mV
0.4
3mV
0.3
2mV
0.2
5mV
5 mV 0.415 mV 0.42 mV 0.42 mV 0.42 mV 0.22 mV 0.16 mV
2 mV 0.19 mV 0.19 mV 0.19 mV 0.19 mV 0.185 mV 0.185 mV
1m
V
0.
12 mV
0.
12 mV
0.
12 mV
0.
12 mV
0.
12 mV
0.
12 mV
Without enhanced bandwidth
40 GS/s
Step gain 2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
500 mV 23.5 mV 16.3 mV 14.5 mV 14.0 mV
200 mV 10.7 mV 6.9 mV 6.1 mV 5.8 mV
100 mV 6.3 mV 3.8 mV 3.2 mV 3.0 mV
50 mV 2.4 mV 1.75 mV 1.6 mV 1.5 mV
20 mV 1.07 mV 0.7 mV 0.63 mV 0.595 mV
10 mV 0.61 mV 0.38 mV 0.32 mV 0.3 mV
5 mV 0.41 mV 0.24 mV 0.18 mV 0.151 mV
2 mV 0.19 mV 0.18 mV 0.115 mV 0.065 mV
1 mV 0.12 mV 0.12 mV 0.115 mV 0.045 mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 1–27
