Tektronix DPO70000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical s pecifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.
)
20 GS/s
Step gain 2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
500 mV 23.0 mV 16.3 mV 14.5 mV 14.0 mV
200 mV 10.5 mV 6.9 mV 6.1 mV 5.8 mV
100 mV 6.25 mV 3.8 mV 3.2 mV 3.0 mV
50 mV 2.4 m V 1.75 mV 1.6 mV 1.5 mV
20 mV 1.04 mV 0.7 mV 0.63 mV 0.595 mV
10 mV 0.605 mV 0.38 mV 0.32 mV 0.3 mV
5 mV 0.4 mV 0.24 mV 0.18 mV 0.151 mV
2 mV 0.19 mV 0.18 mV 0.115 mV 0.065 mV
1 mV 0.12 mV 0.12 mV 0.115 m
V
0.045 m
V
10 GS/
s
Step g
ain
2.5 GH
z
0.5 GH
z
0.25 G
Hz
0.02 G
Hz
500 mV 22.8 mV 16.3 mV 14.5 mV 14.0 mV
200 mV 10.4 mV 6.9 mV 6.1 mV 5.8 mV
100 m
V
6.15
mV
3.8 m
V
3.2 m
V
3.0 m
V
50 mV 2.4 m V 1.75 mV 1.6 mV 1.5 mV
20 mV 1.035 mV 0.7 mV 0.63 mV 0.595 mV
10 m
V
0.5
9mV
0.3
8mV
0.3
2mV
0.3
mV
5 mV 0.395 mV 0.24 mV 0.18 mV 0.151 mV
2 mV 0.19 mV 0.18 mV 0.115 mV 0.065 mV
1m
V
0.
12 mV
0.
12 mV
0.
115 mV
0.
045 mV
D
PO7254
Enhanced bandwidth
40 GS/s
Step gain 2.5 GHz 2.0 GHz 1.0 GHz 0.5 GHz
500 mV 19.7 mV 16.2 mV 12.1 mV 9.9 mV
200 mV 8.71 mV 6.97 mV 4.97 mV 4.0 mV
100 mV 5.23 mV 4.25 mV 2.97 mV 2.36 mV
50mV 2.0mV 1.64mV 1.23mV 1.03mV
20 mV 0.866 mV 0.707 mV 0.528 mV 0.431 mV
10 mV 0.523 mV 0.425 mV 0.297 mV 0.236 mV
5 mV 0.343 mV 0.349 mV 0.21 mV 0.154 mV
2 mV 0.135 mV 0.135 mV 0.135 mV 0.135 mV
1 mV 0.095 mV 0.095 mV 0.095 mV 0.095 mV
1–28 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
