Command Groups
Table 2-39: Search Commands (cont.)
Command Description
SEARCH:SEARCH<x>:TRIGger:A:SETHold:CLOCk:
THReshold
This command specifies the clock threshold setting for an setup/hold
search
SEARCH:SEARCH<x>:TRIGger:A:SETHold:DATa:SOUrce This command specifies the data source setting for an setup/hold
search
SEARCH:SEARCH<x>:TRIGger:A:SETHold:DATa:
THReshold
This command specifies the data threshold s etting for an setup/hold
search
SEARCH:SEARCH<x>:TRIGger:A:SETHold:HOLD Time This command specifies the hold time setting for an setup/hold
search
SEARCH:SEARCH<x>:TRIGger:A:SETHold:SETTime This command specifies the setup time setting for an setup/hold
search
SEARCH:SEARCH<x>:TRIGger:A:SETHold:THReshold{:
MATH|:MATH1}
This command specifies the search setup and hold threshold for
the math waveform
SEARCH:SEARCH<x>:TRIGger:A:SETHold:THReshold:
REF<x>
This command specifies the search setup and hold threshold for
the selected reference waveform
SEARCH:SEARCH<x>:TRIGger:A:TIMEOut:POLarity
When searching using the
TIMEOut search type, this commands
specifies the polarity to be used.
SEARCH:SEARCH<x>:TRIGger:A:TIMEOut:S OU rce
When searching using the
TIMEOut search type, this command
specifies the source.
SEARCH:SEARC H<x >:T R IGger:A:TIMEOut:TIMe
When searching using the
TIMEOut search type, this command
specifies the timeout time, in seconds.
SEARCH:SEARCH<x>:TRIGger:A{:TRANsition|:RISEFall}:
DELTatime
This command specifies the transition time setting for an transition
search
SEARCH:SEARCH<x>:TRIGger:A{:TRANsition|:RISEFall}:
POLarity
This command specifies the polarity setting for a transition search
SEARCH:SEARCH<x>:TRIGger:A{:TRANsition|:RISEFall}:
SOUrce
This command specifies the source setting for a transition search
SEARCH:SEARCH<x>:TRIGger:A{:TRANsition|:RISEFall}:
WHEn
This command specifies the condition setting for a transition search
SEARCH:SEARCH<x>:TRIGger:A:TYPe This command specifies the search type, ie.
EDGe|PULSEWidth|SETHold|RUNt|TRANsition|LOGIc|TIMEOut|BUS.
SEARCH:SEARCH<x>:TRIGger:A:UPPerthreshold:CH<x> This command specifies the waveform upper threshold level for
all channel waveform searches.
SEARCH:SEARCH<x>:TRIGger:A:UPPerthreshold:MATH This command specifies the waveform upper threshold level for all
math waveform searches.
SEARCH:SEARCH<x>:TRIGger:A:UPPerthreshold:REF<x> This command specifies the waveform upper threshold level for all
reference waveform searches.
SEARCH:SEARCH<x>:TRIGger:A:UPPerthreshold:
RF_AMPlitude
For a runt or transition search using the RF Amplitude vs. Time
trace, this command specifies the upper threshold to be used by
the search engine.
2-74 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
