Command Groups
Table 2-41: Trigger Commands (cont.)
Command
Description
TRIGger:A:PULSEWidth:LOWLimit This command specifies the lower limit to use, in seconds, when triggering
on detection of a pulse whose duration is inside or outside a range of two
values. (Use TRIGger:A:PULSEWidth:HIGHLimit to specify the upper limit
of the range.)
TRIGger:A:PULSEWidth:POLarity This command specifies the polarity for the A pulse width trigger
TRIGger:A:PULSEWidth:SOUrce This command specifies the source for the pulse width trigger
TRIGger:A:PULSEWidth:WHEn This command specifies to trigger when a pulse is detected with a
width (duration) that is less than, greater than, equal to, or unequal to a
specified value (set using TRIGger:A:PULSEWidth:WIDth), OR whose
width falls outside of or within a specified range of two values (set using
TRIGger:A:PULSEWidth:LOWLimit and TRIGger:A:PULSEWidth:HIGHLimit ).
TRIGger:A:PULSEWidth:WIDth This command specifies the pulse width (duration), in seconds, for triggering
on pulses whose widths are greater than, less than, equal to, or not equal
to the specified value.
TRIGger:A:RUNT ?
Returns the current A runt pulse trigger logic parameters
TRIGger:A:RUNT:POLarity This command specifies the polarity for the A pulse runt trigger
TRIGger:A:RUNT:SOUrce This command specifies the source for the A pulse trigger
TRIGger:A:RUNT:WHEn This command specifies the type of pulse width the trigger checks for when it
uncovers a runt
TRIGger:A:RUNT:WIDth This command specifies the minimum width for A pulse runt trigger
TRIGger:A:SETH old? Returns settings for setup and hold violation triggering
TRIGger:A:SETHo ld:C LOCk? Returns clock edge polarity, voltage threshold and source input for s etup/hold
triggering
TRIGger:A:SETHo ld:C LOC k:ED G E This command specifies the clock edge polarity for setup and hold triggering
TRIGger:A:SETHo ld:C LOC k:SOUrce This command specifies the clock source for the A logic trigger setup and
hold input
TRIGger:A:SETHold:CLOCk:THReshold This command speci fies the clock voltage threshold for setup and hold trigger
TRIGger:A:SETHo ld:D ATa? Returns the voltage threshold and data source for the setup/hold trigger
TRIGger:A:SETHold:DATa:SOUrce This command specifies the data source for the setup and hold trigger
TRIGger:A:SETHold:DATa:THReshold This command specifies the data voltage threshold for setup and hold trigger
TRIGger:A:SETH old:HOLDTime This command specifies the hold time for the setup and hold violation triggering
TRIGger:A:SETHo ld:SETTime This command specifies the setup time for setup and hold violation triggering
TRIGger:A:SETHold:THReshold:CH<x> Sets or queries the threshold for the channel
TRIGger:A:SETHold:THReshold:D<x> Sets the A trigger setup and hold threshold for the selected digital channel
TRIGger:A:TIMEOut:PO Larity When triggering using the TIMEOut trigger type, this commands specifies
the polarity to be used.
TRIGger:A:TIMEOut:SO Urce When triggering using the TIMEOut trigger type, this command specifies the
source. The available sources are live channels, external (or auxillary) input,
and digital channels. The default is channel 1.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-89
