Commands Listed in Alphabetical Order
NOTE. Once this
command is used to specify QTAG, then the command
TRIGger:A:BUS:B<x>:ETHERnet:CONDition canbeusedtospecifyQTAG
as the condition to trigger on.
Conditions
This command requires a DPO4ENET application module for DPO/MSO4000B
and MDO4000/B/C models.
Group
Trigger
Syntax
TRIGger:A:BUS:B<x>:ETHERnet:FRAMETYPe {BASic|QTAG}
TRIGger:A:BUS:B<x>:ETHERnet:FRAMETYPe?
Related Commands
TRIGger:A:BUS:B<x>:ETHERnet:CONDition
Arguments
BASic is the standard Ethernet frame.
QTAG is the Q-Tag Ethernet frame (also called VLAN tagging.)
Examples
TRIGger:A:BUS:B1:ETHERnet:FRAMETYPe QTAG sets the frame type to
QTag (VLAN tagging).
TRIGger:A:BUS:B1:ETHERnet:FRAMETYPe? might return BASIC, indicating
the frame type is a standard Ethernet frame.
TRIGger:A:BUS:B<x>:ETHERnet:IPHeader:DESTinationaddr:VALue
When the Ethernet trigger condition is set to IPHeader, this command specifies
the value of the 32–bit destination address that is to be used in the trigger (along
with the source address and protocol value). The IP destination address is a
standard IP address such as 192.168.0.1. The default is all X’s (don’t care).
B<x>
is the bus number B1-B4.
Conditions
This command requires a DPO4ENET application module for DPO/MSO4000B
and MDO4000/B/C models.
Group
Trigger
Syntax
TRIGger:A:BUS:B<x>:ETHERnet:IPHeader:D ESTinationaddr:VALue
<QString>
TRIGger:A:BUS:B<x>:ETHERnet:IPHeader:D ESTinationaddr:VALue?
2-798 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
