Commands Listed in Alphabetical Order
Related Commands
TRIGger:A:BUS
:B<x>:ETHERnet:CONDition
TRIGger:A:BUS:B<x>:ETHERnet:IPHeader:SOUrceaddr:VALue
TRIGger:A:BUS:B<x>:ETHERnet:IPHeader:PROTOcol:VALue
BUS:B<x>:ETHERnet:PROTOcol
Arguments
QString is a quoted string of up to 32 characters where the allowable characters
are 0, 1, and X. The bits specified in the quoted string replace the least significant
bits, leaving any unspecified upper bits unchanged.
Examples
TRIGger:A:BUS:B1:ETHERnet:IPHeader:DES Tinationaddr:VALue
“00011001001000010110100000000001”
sets the IP destination address
to trigger on to 192.168.0.1.
TRIGger:A:BUS:B1:ETHERnet:IPHeader:DES Tinationaddr:VALue
might return "XXXXXXXXXXXXXXXXXXXXXXXXXXXXXX01".
TRIGger:A:BUS:B<x>:ETHERnet:IPHeader:PROTOcol:VALue
When the Ethernet trigger condition is set to IPHea der , this command specifies
the value of the 8–bit protocol field that is to be used in the trigger (along with
the source and destination addresses). The default is all X’s (don’t care).
B<x> is
the bus number B1-B4.
NOTE. Commonly used protocol values are 1 (ICMP), 2 (IGMP), 6 (TCP) and
17 (UDP).
Conditions
This command requires a DPO4ENET application module for DPO/MSO4000B
and MDO4000/B/C models.
Group
Trigger
Syntax
TRIGger:A:BUS:B<x>:ETHERnet:IPHeader:P ROTOcol:VALue
<QString>
TRIGger:A:BUS:B<x>:ETHERnet:IPHeader:P ROTOcol:VALue?
Related Commands
TRIGger:A:BUS:B<x>:ETHERnet:CONDition
TRIGger:A:BUS:B<x>:ETHERnet:IPHeader:SOUrceaddr:VALue
TRIGger:A:BUS:B<x>:ETHERnet:IPHeader:DESTinationaddr:VALue
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-799
