Tektronix MDO3000 Series Program Manual

Command Groups
Table 2-39: Search Commands (cont.)
Command Description
SEARCH:SEARCH<x>:TRIG:A:BUS:B<x>:ETHER:MAC:
ADDR:DEST:VAL
When the Ethernet search condition is set to
MACADDress ,this
command specifies the 48–bit MAC destination address value that
is to be used in the search (along with the source address value).
SEARCH:SEARCH<x>:TRIG:A:BUS:B<x>:ETHER:MAC:
ADDR:SOU:VAL
When the Ethernet search condition is set to
MACADDress ,this
command specifies the 48–bit MAC source address value that is to
be used in the search (along with the destination address value).
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:ETHERnet:
MAC{:LENgth|:TYPe}:?HIVALue
When the Ethernet search condition is set to
MACLENgth, and the
qualifier is set to either
INrange or OUTrange, this command
specifies the upper data value of this range.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:ETHERnet:
MAC{:LENgth|:TYPe}:VALue
When the Ethernet search condition is set to
MACLENgth,and
the qualifier is set to
LESSthan, MOREthan, EQual,
UNEQual, LESSEQual
or M OREEQual, this command
specifies the 16–bit value to search for.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:ETHERnet:
QTAG:VALue
When the Ethernet search condition is set to
QTAG, this command
specifies the 32–bit QTAG value to search for.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:ETHERnet:
QUALifier
This command specifies the qualifier to be used when the Ethernet
search condition is set to
MACLENgth or DATa.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:ETHERnet:
TCPHeader:ACKnum:VALue
When the Ethernet search condition is set to
TCPHeader,this
command specifies the 32–bit acknowledgement value that is to
be used in the search (along with the destination and source port
addresses and the sequence number). The default is all X’s (don’t
care).
SEARCH:SEARCH<x>:TRIG:A:BUS:B<x>:ETHER:TCPH:
DEST:VAL
When the Ethernet search condition is set to
TCPHeader,this
command specifies the 16–bit destination port address that is to be
used in the search (along with the acknowledgement value, source
port address and the sequence number).
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:ETHERnet:
TCPHeader:SEQnum:VALue
When the Ethernet search condition is set to
TCPHEADER,this
command specifies the 32–bit sequence number that is to be used
in the search (along with the desti nation and source port addresses
and the acknowledgement value).
SEARCH:SEARCH<x>:TRIG:A:BUS:B<x>:ETHER:TCPH:
SOU:VAL
When the Ethernet search condition is set to
TCPHEADER,this
command specifies the 16–bit source port address that is to be
used in the search (along with the destination port address, the
sequence number and the acknowledgement number).
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:
CONDition
This command specifies the condition to use when searching on
FlexRay bus data (start of frame, frame type, ID, cycle count,
header, data, ID and data, EO F, error).
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:
CYCLEcount:HIVALue
This command specifies the upper data value of the range to be
used when searching on the FlexRay bus cycle count field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:
CYCLEcount:QUALifier
This command speci fies the qualifier (<, >, =, <=, >=, not =, in
range, out of range) to use when searching on the FlexRay bus
cycle count field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:
CYCLEcount:VALue
This command specifies the low data value to be used when
searching on the FlexRay bus cycle count field.
