Tektronix MDO3000 Series Program Manual

Command Groups
Table 2-39: Search Commands (cont.)
Command Description
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
DATa:HIVALue
This command specifies the high value to use when searching on
the FlexRay bus data field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
DATa:OFFSet
This command specifies the offset of the data s tring in bytes to be
used when searching on the FlexRay bus data field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
DATa:QUALifier
This command specifies the qualifier (<, >, =, <=, >=, not =, in range,
out of range) to use when searching on the FlexRay bus data field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
DATa:SIZe
This command specifies the length of the data string, in bytes, to
use when searching on the FlexRay bus data field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
DATa:VALue
This command specifies the low value to use when searching o n
the FlexRay bus data field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
EOFTYPE
This command specifies which end of file type to use (static,
dynamic or any) when searching on the FlexRay bus EOF field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
ERRTYPE
This command specifies the error type to use when searching on
the FlexRay bus signal.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
FRAMEID:HIVALue
This command specifies the high value to use when searching on
the FlexRay bus frame ID field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
FRAMEID:QUALifier
This command specifies the qualifier to use when searching on
the FlexRay bus frame ID field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
FRAMEID:VALue
This command specifies the low value to use when searching o n
the FlexRay bus frame ID field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
FRAMEType
This command specifies the frame type (normal, payload, null, sync
or startup) to use when searching on FlexRay bus data.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
HEADER:CRC
This command specifies the CRC portion of the binary header string
to be used when searching on FlexRay bus data.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
HEADER:CYCLEcount
This command specifies to use the cycle count portion of the binary
header string when searching on the FlexRay bus header.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
HEADER:FRAMEID
This command specifies to use the frame ID portion of the binary
header string when searching on the FlexRay bus header.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
HEADER:INDBits
This command specifies to use the indicator bits portion of the
binary header string when searching on the FlexRay bus header.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEX ray:
HEADER:PAYLength
This command specifies to use the payload length portion of the
binary header string when searching on the FlexRay bus header.
SEARCH:SEARC H<x >:T R IGger:A:BUS:B<x>:I2C:ADDR e ss:
MODe
This command specifies the I2C address mode to 7 or 10-Bit
SEARCH:SEARC H<x >:T R IGger:A:BUS:B<x>:I2C:ADDR e ss:
TYPe
This command specifies the I2C address type to I2C special
addresses
SEARCH:SEARC H<x >:T R IGger:A:BUS:B<x>:I2C:ADDR e ss:
VALue
This command specifies the binary address string to be used for
I2C search
SEARCH:SEARC H<x >:T R IGger:A:BUS:B<x>:I2C:COND ition This command specifies the search condition for I2C search
SEARCH:SEARC H<x >:T R IGger:A:BUS:B<x>:I2C:DATa:
DIRection
This command specifies the I2C search condition to be valid on a
READ, WRITE or either
2-66 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
