Tektronix MDO3000 Series Program Manual

Command Groups
Table 2-39: Search Commands (cont.)
Command Description
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:CA N:DATa:
QUALifier
This command sets the qualifier (<, >, =, not =, <=) to be used to
search on CAN bus data.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:CA N:DATa:
SIZe
This command sets the length of the data string, in bytes, to be
used to search on CAN bus data.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:CA N:DATa:
VALue
This command sets the binary data value to be used to search on
CAN bus data.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:CA N:FD:
BRSBIT
This command sets the value (don’t care, 1, or 0) to be used to
search for CAN FD BRS bits.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:CA N:FD:
ESIBIT
This command sets the value (don’t care, 1, or 0) to be used to
search for CAN FD ESI bits.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:CA N:
FRAMEtype
This command sets the frame type (data, remote, error or overload)
to be used to search on CAN bus data.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:CA N{:
IDentifier|:ADDRess}:MODe
This command sets the addressing mode (standard or extended
format) to be used to search on CAN bus data.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:CA N{:
IDentifier|:ADDRess}:VALue
This command sets the binary address v alue to be used to search
on CAN bus data.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ETHERn et:
CONDition
When searching through Ethernet data, this command specifies the
field or condition to search on.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ETHERn et:
DATa:HIVALue
When the search condition is set to DATa, and the qualifier is set
to either
INrange or OUTrange, this command specifies the
upper data value of the range.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ETHERn et:
DATa:OFFSet
When the search condition is set to DATa, this command specifies
where in the data field to look for the data search value.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ETHERn et:
DATa:SIZe
When the search condition is set to DATa, this command specifies
the number of contiguous TCP/IPv4/MAC client data bytes to
search for.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ETHERn et:
DATa:VALue
When the search condition is set to DATa, and the qualifier is set to
LESSthan, MOREthan, EQual, UNEQual, LESSEQual
or MORE EQual, this command specifies the value to search on.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ETHERn et:
FRAMETYPe
This command specifies which Ethernet frame type to search on:
either Basic or QTAG (IEEE 802.1Q , or VLAN tagging).
SEARCH:SEARC H<x >:T R IG:A:BU S:B<x>:ET H ER:IPH:
DEST:VAL
When the Ethernet search condition is set to
IPHeader,this
command specifies the value of the 32–bit destination address that
is to be used in the search (along with the protocol and source
address).
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ETHERn et:
IPHeader:PROTOcol:VALue
When the Ethernet search condition is set to
IPHeader,this
command specifies the value of the 8–bit protocol field that is
to be used in the search (along with the source and destination
addresses).
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ETHERn et:
IPHeader:SOUrceaddr:VALue
When the Ethernet search condition is set to
IPHeader,this
command specifies the value of the 32–bit source address that
will be used in the search (along with the protocol and destination
address).
2-64 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
