Acquire the Sign
al
1. Push BW to bring
up the resolution
bandwidth side menu. This allows you to set
the smallest frequency difference that the
instrument can
discern in the frequency axis.
Bandwidth
2. Push RBW Mode
to select either Auto or
Manual.
Auto sets the resolution bandwidth
automatica
lly as you change the span. The
default behavior is RBW = Span/1000.
Manual allows you to set your own
resolution
bandwidth.
RBW
Mode
Auto
Manual
3. To manually adjust the RBW, push RBW
and turn Multipurpose a.
RBW
(a)
600 kHz
(Auto)
4. Push Span
:RBWand turn M u ltipurpose
a to set the span/RBW ratio.
ThisratioisusedwhentheRBW Mode is
set to Aut
o. The default is 1000:1 but you
can set it to other values in a 1-2-5 sequence
(e.g. 1000, 20000, 50000).
Span :
RBW
1000 : 1
5. Push Win
dow and turn Multipurpose a to
choose which FFT window type to use.
The choices are: Kaiser, Rectangular,
Hammin
g, Hanning, Blackman-Harris, or
Flat-Top.
Window
Kaiser
The RF
bandwidth FFT feature provides six windows. Each offers a trade-off between frequency resolution and magnitude
accuracy. The choice of which window to use depends upon what you want to measure and your source’s signal
characteristics. Use the following guidelines to select the best window:
MDO3000 Series Oscilloscopes User Manual 87

Tektronix MDO3024 Specifications

General

Analog Channels	4
Bandwidth	200 MHz
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Digital Channels	16 (optional)
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Digital Voltmeter	4-digit
Vertical Resolution	8 bits
Operating Temperature	0 °C to +50 °C
Display	9-inch WVGA (800x480) color display
Connectivity	USB, LAN, GPIB (optional)
Arbitrary Function Generator	50 MHz
Trigger Modes	Edge, Pulse Width, Logic, Video, Runt, Rise/Fall Time, Setup/Hold
Input Impedance	1 MΩ ±1%
Max Input Voltage	300 VRMS
Trigger Types	Edge, Pulse Width, Logic, Video, Runt, Rise/Fall Time, Setup/Hold
